روناک صنعت رامونا ( با مسئولیت محدود )

Bucket Elevator
Bucket ElevatorBucket ElevatorBucket ElevatorBucket ElevatorBucket Elevator

الواتور



سیستم انتقال در ارتفاع  الواتور :

Bucket Elevator




►Technical data:

Model TZD200 TZD250 TZD300 TZD400 TZD500
Capacity (t/h) 50~80 80~120 150~210 200~300 350~400
Bucket Speed (m/s) 2~3.1 2~3.1 2.5~3.5 2.5~3.5 3.2~3.9
Bucket Capacity (L) 1.21 2.35 6 8.4 10.9
Bucket Distance (mm) 105 125 215 215 215
Bucket Width (mm) 186 238 280 380 480
Belt Width (mm) 200 250 300 400 500
Head Pulley Diameter (mm) 630 630 710 710 800
Model TZD650 TZD800 TZD1000 TZD1200
Capacity (t/h) 380~450 500~600 700~800 900~1000
Bucket Speed (m/s) 3.2~3.9 3.2~4.0 3.2~4.0 3.2~4.0
Bucket Capacity (L) 2×6 2x8x4 2x10x9 2x12x9
Bucket Distance (mm) 215 215 215 215
Bucket Width (mm) 2×280 2×380 2×480 2×580
Belt Width (mm) 650 800 1000 1200
Head Pulley Diameter (mm) 800 1140 1140 1140
